B06BG2: Base-Isolated IEPE Accelerometer from LNS®
B06BG2 Base-Isolated IEPE Accelerometer
To meet the demands of precision testing environments — especially where signal quality is threatened by electromagnetic interference or ground loops — LNS® introduces the B06BG2, a compact voltage-type accelerometer featuring base isolation.
This sensor is ideal for applications in power monitoring, rotating machinery diagnostics, and structural vibration analysis. Designed with a shear-mode piezoelectric element and M5 or 10-32 side connector, the B06BG2 delivers accurate measurements with a rugged, space-saving design.
✨ Key Features
- Compact and lightweight form factor
- Shear structure for superior stability
- Miniature design with full ground isolation
- M5 or 10-32 side connector
- Versatile mounting options
📐 Technical Specifications
| Parameter | Value |
|---|---|
| Sensitivity (±10%) | 100 mV/g |
| Measurement Range | ±50 g |
| Frequency Response (±5%) | 1 Hz – 7,000 Hz |
| Frequency Response (±10%) | 0.5 Hz – 10,000 Hz |
| Resonant Frequency | > 35 kHz |
| Transverse Sensitivity | < 5% |
| Base Strain Sensitivity | < 0.01 g/με |
| Output Type | IEPE |
| Bias Voltage | 8–12 VDC |
| Operating Temperature Range | –50°C to +120°C |
| Connector Type | M5 or 10-32 Side |
| Isolation | >10⁸ Ohm to case |
| Weight | ~7.8 grams |
| Housing Material | Titanium Alloy |
| Mounting | M5 or 10-32 Female |
| Protection Grade | IP67 |
🛠 Application Examples
🔌 Power Equipment Monitoring
Detects directional vibration signals while rejecting EMI and leakage currents from high-voltage equipment.
⚙️ Machinery Fault Diagnosis
Mounts directly to bearing housings to identify misalignment, looseness, or wear in rotating machinery.
🧪 Structural and R&D Testing
Applicable to modal testing, fatigue analysis, and high-resolution vibration studies across various industries.
Also available in 5mV/g, 10mV/g, 20mV/g, and 50mV/g variations.
