B05H01 – LNS® IEPE Embedded Accelerometer
To meet the demand for shock and vibration measurements in high-volume and OEM applications, LNS® has developed the IEPE embedded accelerometer B05H01. This sensor features a compact design that enhances value-added monitoring and protection. It has an internal compression-type core and an external stainless steel casing, laser-welded for durability and broad bandwidth performance, ensuring stability and reliability during use.
Product Features:
- Compact design with a small size and lightweight structure.
- Integrated, miniaturized circuitry with low power consumption.
- Stable and reliable compression-type core across the entire series.
- Embedded design with pin output.
- Available in multiple sensitivity options from 10-100 mV/g.
Main Specifications:
- Characteristics | Units | B05H01
- Sensitivity | mV/g | 50
- Measurement Range | g | ±25
- Frequency Response ±3dB | Hz | 1-13k
- Amplitude Linearity | % | ≤1
- Transverse Sensitivity | % | ≤5
- Resonant Frequency | kHz | ≥25
- Time Constant | s | ≤1
- Resolution | grms | 0.0002
- Base Strain | g/ε | 0.0008
- Shock Limit | 1gpk | 5000
- Max Vibration | 2grms | 500
- Sensitivity Temperature Coefficient | %/°C | -0.07
- Operating Temperature | °C | -50 to 120
- Sealing Standard | IP68 | Laser Welding
Electrical Parameters
- Supply Voltage | VDC | 3-5.5
- Full-Scale Output Voltage | V | ±1.25
- DC Bias | V | 2.5
- Output Impedance | Ω | ≤1000
Structure
- Sensing Element: Piezoelectric Ceramic
- Housing Material: 304L Stainless Steel
- Sealing: Laser Welding, IP68
- Output Connector: Pin-type
- Mounting Type: Pin-type, Soldered
- Ground Insulation: Ω –
- Weight: 4.5 g
- Recommended Installation Torque: N·m –
Application Scenarios:
- Used in CNC machines and other precision processing equipment to monitor vibration during operation, ensuring processing accuracy and quality.
- Vibration and shock measurement in wireless and battery-powered IoT solutions.
